Countersunk
These holding solenoids are very space-saving due to their countersunk design. They can be easily mounted on the front of various supports, e.g. doors, walls, ceilings, window frames, etc., using countersunk screws.
- space-saving
- easy to install
Specifications and technical details:
- Size HF [mm]
- ø16-40
- Height HF [mm]
- 4,5-8
- Power HF [N]
- 18-90
- Size NdFeB [mm]
- ø16-40
- Height NdFeB [mm]
- 4,5-8
- Power NdFeB [N]
- 55-400
Particularly suitable for:
- Office materials
- Dispensary
- Shopfitting
- Warehouse logistics
- Organization
- Toolmaking
Models of our holding magnets with countersunk | HF
| Ø [mm] | Height [mm] | ØD1 [mm] | ØD2 [mm] | t [mm] | weight [g] | Holding Force [N] | Shop |
|---|---|---|---|---|---|---|---|
| 16 | 4.5 | 3,5 | 6.5 | 1.6 | 4 | 12 | |
| 20 | 6 | 4,2 | 8.6 | 2.1 | 9 | 27 | |
| 25 | 7 | 5,5 | 10.4 | 2.5 | 16 | 36 | |
| 32 | 7 | 5,5 | 10.4 | 2.5 | 16 | 36 | |
| 40 | 8 | 5,5 | 10.4 | 2.5 | 53 | 90 |
